Pair Ceiling Loudspeakers

/ EU SAP:

Slim bezel-less magnetic grille
Premium Kevlar 6.5″ Woofer
Large 0.75″ Titanium Tweeter
Passive Crossover

Stock levels @ 28-July-21
  • Total 206
  • EU 93
  • UK 113
  • Share on
  • or

Redesigned from the ground up, the CS-1900 ceiling speakers are loaded with quality components resulting in clean, powerful sound. They use the ceiling void as an infinite baffle – allowing un-restricted driver excursion – all of which adds up more bass. Low impedance speakers like these offer better sound that 100/70v line speakers. Perfect for meeting spaces.

Features

  • Front EQ

    The simple attenuation switch on the front allows the user to fine-tune the EQ for the environment.

  • Titanium Dome

    The large tweeter is made from premium material and pivots to help installers setup the soundscape. Titanium ensures long, stable performance and reduces distortion.

  • Woven Kevlar

    Kevlar gives smooth audio with incredible detail and transparency. The cone is held in place with a butyl rubber surround to extend the life of the loudspeaker.

  • Magnetic Grill

    The grill clips into place magnetically once the speakers are secured.

  • Invisible

    The grill extends all the way to the edge of the speaker resulting in virtually no visible edge. This ultra thin grille allows the technology to visually disappear.

  • Simple to fit

    A cutout template is included so the installer can easily trace the cut line in the ceiling tile. Cut a 210 mm (8.3″) hole and turn the dog-leg screws from below to fix the speaker; it’s quick and easy.

  • Shallow

    Only 87 mm (3.4″) deep, the CS-1900 can be placed anywhere around the room to optimally disperse the sound. They fit in any environment which has a false ceiling.

  • Crossover

    Gold plated terminals and a quality crossover circuit is included which splits the work between the woofer and tweeter.

  • High Sensitivity

    Ceiling speakers often lack the power of wall speakers, but these have a higher sensitivity of 90dB to cut through high-noise presentation environments.

  • Thick Ceiling?

    The clamps are an extra long 35 mm (1.4") to cope with ceilings made of very thick material. Most ceiling speakers can only cope with tiles up to 15 mm (0.6") thick.

Specifications

  • LOUDSPEAKER DIMENSIONS

    227 x 87 mm/ 9.0″ x 3.6″

  • CUTOUT SIZE

    210 mm / 8.3″

  • CARTON DIMENSIONS

    267 x 265 x 225 mm / 10.5″ x 10.4″ x 8.9″ (contains a pair)

  • SPEAKER WEIGHT

    1.52 kg / 3.4 lbs (each)

  • CARTON WEIGHT

    4 kg / 8.8 lbs (contains a pair)

  • POWER HANDLING

    60 Watt RMS

  • WOOFER

    6.5″ Woven Kevlar

  • TWEETER

    0.75″ Titanium Dome

  • CONTRUCTION MATERIAL

    ABS Plastic

  • SPEAKER TERMINALS

    Spring post

  • NOMINAL IMPEDANCE

    8 ohms

  • SENSITIVITY

    90 dB (1w/1m)

  • FREQUENCY RESPONSE

    60Hz-20kHz

  • COLOUR

    Cone: Yellow
    Basket: Black
    Grill: White

  • WARRANTY

    Lifetime return-to-base

  • COMPLIANCES

    RoHS, WEEE, REACH

  • ORDER PART CODE

    CS-1900 [EU SAP: 4815044 / US SAP: tba]

  • Country of Origin

    China

  • ISO

    ISO 9001:2015
