Black USB-C Cable 10m | Vision Audio Visual

Cables
USB-C

Black USB-C Cable 10m

Part Number: SAP: EAN:
  • Optical Cable
  • Backwards compatible with USB 2.0
  • Transfers USB data and DisplayPort video data
Stock levels @ 20-December-24
  • Total 0
Incoming stock ETA
  • 100 EU @ 22-Jan-25 UK @ 29-Jan-25
  • Share on
  • or

USB-C is the latest USB connector. It has a smaller reversible plug which supports USB 3.2 Gen 1 signal.

This cable is compatible with both 2-lane and 4-lane configurations. For a 4-lane connection, both connected devices must support 4 lanes.

Features

  • Very Tough

    This cable, reinforced with a Kevlar core, is designed to resist stretching forces. It can withstand a continuous force of up to 200 newtons or a momentary peak force of up to 400 newtons.

  • Tight Bends

    Fiber cables boast a significantly tighter bend radius compared to copper cables. This particular cable features a dynamic bend radius of 20 mm and a static bend radius of 10 mm.

  • Directional

    This cable contains a chip integrated into each connector, so the end marked 'display' must be connected to the display. The ends are not interchangeable.

Specifications

  • PACKAGED WEIGHT

    0.85 kg (1.87 lb)

  • PACKAGED DIMENSIONS

    175 mm x 150 mm x 50 mm (6.9" x 5.9" x 1.9")

  • SHEATH

    PVC

  • FILLER

    Kevlar

  • PLUG DIMENSIONS

    44 mm x 13 mm x 8 mm (1.7" x 0.5" x 0.3")

  • OUTER DIAMETER

    6.5 mm (0.3")

  • DATA TRANSFER RATE

    2 lane supports DP 1.4 (2 x 8.1 = 16.2 Gbps) and USB 2.0 (480 Mbps)
    4 lane supports DP 2.1 (4 x 10 = 40 Gbps) and USB 3.2 (10 Gbps)
    Note: the number of lanes are limited by the source or display

  • CHARGING CURRENT

    3 A (60 watts)

  • USB VERSION

    Type-C plug

  • POWER CONSUMPTION

    1200 mW (5V input)

  • DP ALT MODE

    Cable can be used for DisplayPort instead of USB

  • MAXIMUM RESOLUTION

    4K @ 60 Hz

  • CONNECTORS

    Nickel plated

  • COMPLIANCE

    RoHS, CE

  • ORDER PART CODE

    TC 10MUSBC/BL [SAP: 10425512]

  • Country of Origin

    China
